Whole Systems & the Integrated Process

Every design decision has two things that move in opposite directions over the life of a project: your ability to influence the outcome, and the cost of making a change. At the very start - a blank sheet, a site, a brief - your ability to influence performance, cost and carbon is at its maximum and it costs almost nothing to explore a different orientation or structure. By the time you are in construction documents, most of the important decisions are locked, and changing them means redrawing, re-coordinating and re-pricing. On site, a change is ruinously expensive. This is the cost-of-change curve, and it is the single most important thing to understand about design process.

The implication for sustainability is stark. The decisions with the largest environmental consequences - building form and orientation (which set heating, cooling and daylight loads for the life of the building), the structural system (which sets most of the embodied carbon), the relationship between the building and its site - are exactly the ones made earliest, when they are cheapest to get right and dearest to fix later. A team that starts thinking about energy and carbon in design development has already surrendered most of its leverage. Worse, late sustainability tends to be additive and expensive - bolting on more solar, more plant, more product to compensate for a form that was never optimised - whereas early sustainability is subtractive and cheap, removing loads before they are ever created. The whole logic of integrated design follows from this one curve: if the big levers are pulled early, the sustainability thinking has to be there early too.

Architect Patrick MacLeamy drew the famous version of this idea, and it is worth carrying as a picture. On his diagram, one curve is the ability to impact cost and performance, sloping down over the project. A second is the cost of design changes, sloping up. A third is the traditional distribution of design effort - which peaks late, in construction documentation, precisely where influence is low and change is expensive. The fourth, and the point of the whole diagram, is the preferred effort curve: front-loaded, peaking in schematic design and design development, where influence is still high and changes are still cheap.

The MacLeamy curve is not just an argument for working harder early; it is an argument for spending your design effort where it pays. In a conventional process, a team does relatively little analysis up front, commits to a scheme, and then does enormous work later detailing a shape whose performance is already largely fixed. In an integrated process, the team invests more early - testing orientations, running quick energy and daylight studies, comparing structural options for carbon - so that by the time it reaches documentation, it is detailing a scheme that is already good. The same total effort, moved forward in time, produces a dramatically better building. This is also why the sibling Building Performance Simulation course matters: fast, early, rough modelling is what makes front-loaded effort productive rather than guesswork.

The integrated design process (IDP) is the working method that puts the curve into practice. Its three principles are simple to state and hard to do well. Whole team, early: architect, structural and services engineers, sustainability consultant, cost consultant, landscape designer, and ideally the client and even the eventual contractor and operator, are in the room from the first weeks - not brought in one after another to react to a scheme that is already fixed. Collaborative, around shared goals: the team agrees measurable targets up front (an energy-use intensity, an embodied-carbon budget, a water strategy) so everyone is designing toward the same numbers rather than defending their own discipline. Iterative: the design cycles through rounds of test-and-refine, often in intensive workshops called charrettes, where options are put up, analysed quickly, and improved together.

Contrast this with the conventional linear process: the architect designs, then hands to the structural engineer, who hands to the services engineer, who sizes plant to cope with whatever the architecture produced. Each hand-off is a chance to lose performance, and no one is responsible for the whole. In an integrated process the services engineer's early input might change the facade so that far less cooling plant is needed at all - a better building and a cheaper one. Rating systems have recognised this: LEED, for instance, awards an Integrative Process credit precisely because the process itself drives outcomes. IDP is more demanding of coordination and trust, and it front-loads fees and time - a real cost. But it is how genuinely high-performing buildings are consistently delivered rather than occasionally lucked into.

The reason integrated process pays is whole-systems thinking - designing the building as one connected system so that a single move solves several problems at once. Treated separately, each green measure looks like an added cost: better glazing costs more, more insulation costs more, a bigger renewable array costs more. Treated as a system, they interact - and the interaction can flip the economics.

The Rocky Mountain Institute's Amory Lovins called the best version of this 'tunnelling through the cost barrier.' The idea: as you improve a building's envelope - orientation, shading, insulation, airtightness, good glazing - the heating and cooling loads fall. Push far enough and the loads drop so low that you can radically downsize or even eliminate the mechanical plant - smaller chillers, less ductwork, sometimes no conventional HVAC at all. The savings on the plant can pay for the better envelope, so the deep-green building can cost the same or less than the shallow-green one, even though each individual green feature cost more. You do not climb a rising cost curve of ever-more-expensive efficiency; you tunnel through it by letting one system's improvement shrink another. This only works if the disciplines are in the room together early, because the person specifying the envelope and the person sizing the plant have to make one decision, not two. Whole-systems synergies - a roof that generates power and harvests water and shades the top floor; a landscape that cools the building and manages stormwater and hosts wildlife - are where regenerative design gets its leverage, and they are invisible to a siloed team.

Pulling the module together: the strategy of sustainability (Lessons 0.1-0.3) only becomes real buildings through process. So a few habits follow that the rest of the course assumes. Set targets at the start - an energy-use intensity, an embodied-carbon budget, a water and biodiversity aim - so the team has shared numbers to design toward. Get the right people in the room early - especially the services and structural engineers and, on ambitious projects, a sustainability consultant (Module 10) - and treat their early input as design information, not late compliance. Front-load the analysis - rough, fast studies of orientation, form, envelope and structure in schematic design, when they can still change everything - and lean on simulation tools for this (the Building Performance Simulation course). Look for synergies before you look for products - ask what one move can do three jobs before you go shopping for green components.

None of this requires a bigger budget; it requires a different sequence and a more collaborative culture, which is why it is a mindset lesson as much as a technical one. It is also honest about its own cost: integrated process asks for more coordination, earlier fees and more trust than the conventional relay, and not every client or contract makes that easy. But it is the difference between sustainability as a line item you pay for and sustainability as a property that emerges from designing well. Every module that follows - passive design, energy, carbon, materials, water, health - assumes this integrated, whole-systems way of working underneath it, so the process you build now is the ground the rest of the course stands on.
