Lesson 8.3 · GIS for Urban Planning

Infrastructure & Utility Planning

Water, sewer and transport as networks the GIS can trace

13 min Interactive lessonFree · open lessonByAmogh N P· Architect & interior designer
The hook

The new colony has water on the plan and no water in the tap. On the map, the main stops one junction short.

Everyone approved the layout; the pipe is drawn; the households exist. Yet no water arrives - because a network is not a picture of lines, it is a chain of connections, and one missing link breaks the whole downstream branch. Infrastructure is the one planning layer where connectivity, not just position, is the fact that matters - and GIS built for networks is what lets you ask the map 'does this actually reach?'

A network is only as strong as its worst-connected node.

Nodes and links: the network data model

A road system, a water grid, a sewer, a power feeder - all share one shape. They are networks: a set of nodes (junctions, valves, substations, road intersections) joined by links (pipe segments, road centrelines, cables) that carry flow. In GIS this is a specific data structure with topology - the links know which nodes they connect, and the nodes know which links meet them.

That topology is what separates a utility layer from a pretty set of lines. With it, the GIS can trace: start at the source and find everything downstream; find the break that isolated a branch; compute the shortest path or the reachable set within a distance. Without it, you have a drawing of a network, not a model of one - and a drawing cannot tell you why the tap is dry.

A utility is a network of nodes and links source unconnected branch node link topology lets the GIS ask: what does the source actually reach?
Zoom
Infrastructure is a network: nodes joined by links, so the GIS can trace flow and reach from a source.

Two lines that touch on screen are not connected unless the topology says so.

Water and sewer as layers

Water supply and sewerage are the classic utility layers, and they behave oppositely: water is a pressurised network pushing outward from a source (reservoir, overhead tank), while sewer is largely a gravity network draining downhill to a treatment works. That difference is why sewer planning leans so heavily on the terrain layer from Module 5 - a sewer that has to run uphill needs a pump, and the DEM tells you where.

On GIS each is its own layer of links with attributes - diameter, material, capacity, laid-date - and nodes with attributes - valves, manholes, pump stations. Modelled this way, you can size a main against the demand of the plots it serves, spot where a proposed colony sits beyond the reach of an existing main, and hold an as-laid record that survives the retirement of the engineer who remembers where the pipes are.

roads water sewer power overlay the networks to find crossings, gaps and clashes
Zoom
Each utility is its own layer; stacked on the road base, they reveal where lines cross and clash.

Transport and the reach of a network

Roads are the network everyone shares, and their planning question is usually reach: what can be got to, from here, within a distance or a time? GIS answers this with network analysis - not a straight-line circle, but a trace along the actual links. The reachable set within, say, 800 m of walking is the service area (or catchment); the best route between two points is the shortest path.

This matters because straight-line distance flatters everything. A clinic 500 m away as the crow flies may be a 1,200 m walk around a rail line or a drain. Planning bus stops, deciding where a new road unlocks land, testing whether a proposed junction over-loads - these are all network questions, and getting them right needs the links, not just the points.

A utility is a network of nodes and links source unconnected branch node link topology lets the GIS ask: what does the source actually reach?
Zoom
Infrastructure is a network: nodes joined by links, so the GIS can trace flow and reach from a source.

PM Gati Shakti: one base for every ministry

For decades each department drew its own infrastructure on its own base - the roads authority, the railways, the power utility, the water board - so lines that should meet on the ground missed on paper, and a road was dug up a month after it was laid to lay a cable. PM Gati Shakti - the National Master Plan is India's answer: a dynamic GIS platform (built on BISAG-N) that integrates more than 550 infrastructure data layers across ministries onto one shared base map.

The planning value is coordination. When every network sits on the same base, you can see the clash before it is built, sequence works so the road is laid after the pipe, and plan multimodal connectivity - port to rail to road - as one system. It is login-gated for institutional users rather than an open download, but conceptually it is the layer-overlay idea from Module 0 scaled to a nation.

Many layers, one platform Roads Railways Power grid Water + gas Telecom Land + forest National Master Plan 550+ integrated layers shared GIS base one base map ends the silo where each department drew its own
Zoom
PM Gati Shakti pulls each ministry's infrastructure layer onto one national GIS platform.

One base map is worth a hundred coordination meetings.

The honest limits

Utility GIS is only as good as its record, and India's records are uneven. Much underground infrastructure was laid before any GIS existed, so 'as-laid' data is often reconstructed from memory and patchy surveys - present on the map, uncertain on the ground. Topology has to be built and checked; two lines that merely touch on screen are not connected until the data says so, and a single un-snapped node silently breaks a trace. Data still lives in departmental silos despite Gati Shakti's ambition. And demand is a moving target - a network sized for today's population is under-sized the day the FAR is raised.

So validate topology before you trust a trace, date-stamp as-laid layers, and treat capacity analysis as a scenario tied to a stated demand.

Data & standards for infrastructure work

PM Gati Shakti — National Master Plan

550+ integrated infrastructure layers across ministries (BISAG-N)

India's shared GIS base for multimodal coordination; login-gated for institutional users.

OGC WFS (Web Feature Service)

Serves queryable vector features (geometry + attributes)

The interoperable way to publish and consume utility network features across agencies and tools.

ISO 19107

Spatial schema - geometry and topology model

The global standard behind proper network topology - the reason a 'connection' is well defined.

Smart Cities — DataSmart Cities

City-level open datasets, some with GIS infrastructure layers

Free open datasets from Smart Cities; the Mission closed in 2025 but the data portal remains reachable.

EPSG:32643 (WGS 84 / UTM 43N)

Projected metre-based CRS over much of India

Measure pipe lengths, buffers and service distances here - never in degrees (EPSG:4326).

Hands-on workshop

Workshop — build a network and find its service area

Take a road layer, build routable topology, and compute the walkable service area around a facility - then compare it against a naive straight-line buffer.

QGIS 3.44 (free) with QuickOSM + Network Analysis, or ArcGIS Pro 3.7 with Network Analyst.

Given & goal
Goal: an 800 m walking service area around one facility, plus the difference from a 800 m circular buffer
Data: OSM roads (via QuickOSM) + one facility point
Time: ~45 minutes
  1. 1Load a road network and a facility point in a metre-based CRS (EPSG:32643). In QGIS: QuickOSM for roads. In ArcGIS Pro: add a street layer or OSM data.
  2. 2Build/validate topology so the network is routable. In QGIS: use the Processing 'Network Analysis' tools (they build the graph from the line layer). In ArcGIS Pro: create a Network Dataset (Network Analyst).
  3. 3Compute the service area (reachable set) at 800 m along the network from the facility. In QGIS: Processing ▸ Network Analysis ▸ Service area (from layer). In ArcGIS Pro: Network Analyst ▸ Service Area, break value 800.
  4. 4Draw a plain 800 m circular buffer around the same point for comparison. In QGIS: Vector ▸ Geoprocessing ▸ Buffer. In ArcGIS Pro: Analysis ▸ Tools ▸ Buffer.
  5. 5Overlay the two and compute the difference (buffer minus network area) to quantify how much the straight-line circle overstates real reach. In QGIS: Vector ▸ Geoprocessing ▸ Difference. In ArcGIS Pro: Analysis ▸ Tools ▸ Erase.

You’ll walk away with
A network-based service area, a comparison against the naive buffer, and a measured statement of how much straight-line distance flatters accessibility.

The worked example

Three altitudes on the same idea

Read the band that fits you — or all three.

For the architectSite, form & environment

Infrastructure availability is a go/no-go for your site. Before promising a client anything, check whether trunk water, sewer and a road of adequate width actually reach the plot on the utility layers - not whether they exist somewhere nearby. A scheme that assumes a connection one junction too far is a scheme that stalls at occupancy.

For the plannerLand use, zoning & infrastructure

You allocate the density; you must fund the network that serves it. Every FAR you raise adds load to water, sewer, drainage and roads. Model those as networks tied to the land-use layer so capacity keeps pace with permitted development, and use Gati Shakti-style shared bases to sequence and coordinate works instead of trenching the same road twice.

For the urban designerStreets, blocks & public realm

The road network is the skeleton of the public realm. Junction density, block permeability and walkable catchments are network properties, and they decide whether a place feels connected or severed. Use service-area analysis to test whether people can actually reach the destinations you are designing streets toward - along the links, not across them.

Misconception check

If two utility lines meet on the map, they are connected and flow will pass between them.

Visual touching is not connection. A network only carries flow where its topology records a shared node - links snapped to a common vertex the data structure recognises. Two lines can overlap pixel-for-pixel on screen yet be topologically separate, so a trace stops dead at the gap. This is why building and validating topology is a required step before any connectivity or service-area analysis.
Try it

Do it yourself

No software needed - just think in nodes and links.

  1. 1Explain, in one sentence, why a water network and a sewer network have opposite relationships to the terrain layer.
  2. 2A clinic is 500 m away in a straight line but a 1,300 m walk. Which distance should a service-area plan use, and why?
  3. 3Describe what 'topology' adds to a set of pipe lines that plain geometry does not.
  4. 4Name three ministries whose layers PM Gati Shakti would bring onto one base, and one clash that base could prevent.
  5. 5Why can an as-laid utility layer be present on the map yet uncertain on the ground?
Take this with you

The one line to carry out

Infrastructure is a network of nodes and links, so the fact that matters is connectivity, not just position - measure reach along the links and validate topology before you trust it. PM Gati Shakti is that idea scaled to a nation: one base map so every network is planned together.
Take it further
References & further reading

Peer-reviewed journals & authoritative standards

  1. 01Miller, H.J. & Shaw, S.-L. — Geographic Information Systems for Transportation: Principles and ApplicationsOxford University Press, 2001.
  2. 02de Smith, M.J., Goodchild, M.F. & Longley, P.A. — Geospatial Analysis: A Comprehensive Guide, 7th ed.Winchelsea Press, 2025.
  3. 03Batty, M. — The New Science of CitiesMIT Press, 2013.
  4. 04Computers, Environment and Urban SystemsElsevier, ongoing.
  5. 05Habitat InternationalElsevier, ongoing.
Related lessons
Recap
Utilities and roads are networks (nodes + links + topology); water pushes from a source, sewer drains downhill; reach is a service-area trace not a circle; Gati Shakti integrates 550+ layers on one base.
Carry forward →

A network only earns its cost if it serves people - so the last lesson turns to who those people are and where the gaps are: population density, accessibility and gap analysis.
