The Revit API Basics

In the Revit API, nearly everything in the model is an Element. Walls, doors, rooms, views, sheets, even wall types are elements. Every element has an ElementId - a stable numeric identity that never changes for the life of that object - which is how you refer to it unambiguously in code, and, as a later lesson shows, how you match a spreadsheet row back to the right wall.

What makes elements useful to script is their parameters. A parameter is a named slot holding a value: Comments, Fire Rating, Mark, Height. You read one by name with LookupParameter, then ask for its value in the right type, because Revit stores different parameters as text, numbers, yes/no flags or references to other elements:

p = wall.LookupParameter("Comments")
if p:                         # None if the parameter does not exist
    text = p.AsString()       # AsDouble / AsInteger / AsValueString / AsElementId
    print(text)

Two honest cautions save hours. First, `LookupParameter` returns `None` when the name does not exist - a different type, a typo, or a shared parameter that is not loaded - so you must check before using it. Second, Revit stores lengths internally in decimal feet regardless of your project units, so a wall height read with AsDouble comes back in feet even in a millimetre project; convert with UnitUtils when you need real-world units. Elements carrying parameters is the whole mental model: to automate Revit is mostly to find the right elements and read or write the right parameters on them.

One more distinction pays off early: parameters come in flavours. Built-in parameters are the ones Revit defines for every project - Comments, Mark, Fire Rating - reachable by name with LookupParameter or, more robustly, through the BuiltInParameter enumeration, which does not break if the interface language changes. Project and shared parameters are ones your template or a family author added, and a shared parameter must be loaded into the project before it exists to look up - a common reason LookupParameter returns None. You do not need to master the taxonomy now; just know that if a parameter you can see in Revit comes back as None in code, the name, the type, or a missing shared-parameter definition is usually why.

You rarely want every element - you want all the walls, or every sheet, or all the doors on one level. The tool for that is the FilteredElementCollector, the standard way the API searches the model. You start a collector on the document, then narrow it with filters, then pull the results into a list.

The two filters you will use constantly are by category and element-versus-type. A category is a kind of thing - OST_Walls, OST_Doors, OST_Sheets in the BuiltInCategory enumeration. And every category has both instances (the actual walls placed in the model) and types (the wall definitions in the family). WhereElementIsNotElementType() keeps the placed instances; you almost always want that:

from Autodesk.Revit.DB import FilteredElementCollector, BuiltInCategory

walls = (FilteredElementCollector(doc)
         .OfCategory(BuiltInCategory.OST_Walls)
         .WhereElementIsNotElementType()
         .ToElements())

print(len(walls))   # how many walls in the model

Where doc comes from depends on how you run the script, which the next section covers. The collector is efficient - it queries Revit's own database rather than looping over the whole model - and it composes: chain .OfClass(...) to filter by API class, or pass a level id to limit by level. Reading it aloud almost describes itself: collect from the document, of category walls, not the types, to elements. Once you can reliably gather exactly the set you mean, everything downstream - reading, auditing, changing - is just a loop over that set.

Reading the model is free. Changing it is not: the Revit API refuses to modify anything unless the change happens inside a transaction. A transaction is a named, all-or-nothing bundle of edits - it either commits as a whole or rolls back as a whole, which is what keeps the model consistent and gives you a single undo step. Try to set a parameter outside one and the API throws an error immediately.

The raw pattern is start, change, commit:

from Autodesk.Revit.DB import Transaction

t = Transaction(doc, "Set wall comments")
t.Start()
for w in walls:
    p = w.LookupParameter("Comments")
    if p:
        p.Set("Checked 2026-08")
t.Commit()

The name you give the transaction ("Set wall comments") is what appears in Revit's undo history, so make it descriptive. Notice that many edits sit inside one transaction - that is deliberate and fast; you do not start a new transaction per wall. How you open a transaction depends on your host. In a Dynamo Python node you do not use Transaction directly - you call TransactionManager.Instance.EnsureInTransaction(doc) before your edits and TransactionManager.Instance.TransactionTaskDone() after, letting Dynamo manage it. In pyRevit you use the raw Transaction above, or the tidy with revit.Transaction("name"): helper that starts and commits for you. The concept is identical everywhere: no change without a transaction, and one transaction can carry a whole batch of edits.

Every script above assumed a variable doc - the open model. Getting it is the one piece that differs by how you run the code, and there are two common hosts worth knowing.

Dynamo you already met: a visual graph with a Python Script node, run from inside Revit. There, you reach the document through Dynamo's services:

import clr
clr.AddReference("RevitServices")
from RevitServices.Persistence import DocumentManager

doc = DocumentManager.Instance.CurrentDBDocument

pyRevit is a different and very popular route: a free, open-source add-in that turns Python scripts into buttons on a Revit ribbon tab. You write a .py file, and pyRevit gives it a toolbar button; click it and the script runs against the live model. In pyRevit the current model is handed to you as __revit__:

doc = __revit__.ActiveUIDocument.Document

Which should you learn? They are complementary. Dynamo shines for graph-shaped, data-flow work and for people who like seeing the pipeline; pyRevit shines for turning a script into a reusable tool your whole office clicks like any other Revit command, and it is closer to writing plain Python. Both call the exact same Revit API - the same FilteredElementCollector, the same parameters, the same transactions - so nothing you learn here is wasted whichever you pick. Start with whichever your studio already uses; the four ideas transfer completely.

A quiet fear stops people using the Revit API: that you must memorise it. You do not, and no one does. The API is vast - thousands of classes and methods across dozens of namespaces - and even seasoned BIM programmers keep the documentation open constantly. Fluency here is not recall; it is knowing the shape of things well enough to find the specific method you need and read whether it does what you want.

The canonical reference is the Revit API documentation for your version, which lists every class, its methods and properties, and what each returns. Because the API changes between releases, the version matters - a method that exists in one year may be renamed or take different arguments in another, which is why an undated forum snippet sometimes fails. A widely used community resource, the RevitAPIDocs site, presents the same reference in a searchable form, and the Revit and Dynamo developer forums are where real problems get worked out. When you search, include the version and the class name; you are looking for the method signature - what it takes and what it gives back - not a finished script to paste.

There is also a fast way to explore the API from inside a running script: print what an object offers. Python's dir() lists the attributes and methods of any object, and type() tells you which class you are holding. Dropped into a Python node or pyRevit script, they turn abstract documentation into something concrete about the exact element in front of you:

wall = walls[0]
print(type(wall))          # the element's class
print([m for m in dir(wall) if not m.startswith("_")])  # its members

This is not cheating; it is the normal working method. You form a rough idea from the docs, confirm it against a real object with dir and print, and adjust. Modern AI coding assistants (covered in Module 10) accelerate the first step - describe what you want and they suggest the collector or method - but they hallucinate API calls that do not exist, especially for the version you are on, so you still verify against the docs and a live object. The literacy that makes all of this work is exactly what this module builds: understand elements, parameters, collectors and transactions, and the rest is a lookup away. Nobody holds the whole API in their head, and you do not need to either.
