RhinoScript & rhino3dm

The gentlest way to script a live Rhino model is rhinoscriptsyntax, conventionally imported as rs. It is a large library of plain, verb-like functions - AddPoint, AddLine, AddCircle, ObjectLayer, MoveObject - that mirror the commands you already know from Rhino's toolbars. It was designed to be approachable for exactly the audience of this course: designers who think in Rhino commands, not in software objects.

import rhinoscriptsyntax as rs

pt = rs.AddPoint(0, 0, 0)
rs.AddCircle(pt, 5.0)
rs.AddTextDot("origin", [0, 0, 0])

Run that in Rhino's Python editor and three objects appear in the open document. That last phrase is the crucial catch: rhinoscriptsyntax only works inside a running Rhino (or a Grasshopper script component), because every function talks to the current Rhino document. Take this code to a plain Python install with no Rhino and the import fails - there is no document for AddPoint to add a point to. rhinoscriptsyntax is a convenience layer; underneath, it calls the real engine, which is our next piece.

What makes rs so welcoming to designers is that its functions map almost one-to-one onto Rhino commands you already run with the mouse, and they mostly take and return simple things - lists of three numbers for points, object identifiers as strings. You can be productive with it after learning barely a dozen functions. The trade is that it hides detail: it is excellent for scripting routine document tasks - drawing, moving, layering, labelling, selecting - and less suited to heavy geometric computation, where you will want the richer objects of RhinoCommon. A good mental model is that rhinoscriptsyntax automates the things you do to a Rhino document, while RhinoCommon lets you compute with geometry itself. Many real scripts use both: rs to fetch and place objects, RhinoCommon for the maths in between.

Historically, rhinoscriptsyntax began as the Python descendant of RhinoScript, an even older scripting language built into Rhino, which is why so much advice online is phrased in its command-like style. For a designer starting today, the takeaway is simple: rs is the approachable on-ramp for automating a Rhino session, and everything you learn there transfers, because the concepts - make an object, move it, put it on a layer - are universal. You will not need most of its hundreds of functions; a working vocabulary of the dozen you use often, plus the confidence to look up the rest, is exactly the done-and-useful fluency this course aims for.

Beneath the friendly rs functions sits RhinoCommon, Rhino's complete geometry and document SDK. When you write import Rhino.Geometry as rg in a Grasshopper script component, you are using RhinoCommon directly. It is more verbose and more object-oriented than rhinoscriptsyntax, but far more powerful - it exposes the actual geometry classes and their methods.

import Rhino.Geometry as rg

circle = rg.Circle(rg.Point3d(0, 0, 0), 5.0)
curve = circle.ToNurbsCurve()
length = curve.GetLength()

The key thing to understand is that RhinoCommon carries the geometry kernel - the mathematics that can trim, split, loft, offset, intersect and boolean real surfaces and solids. That kernel is heavy and proprietary, and it only exists where Rhino (or Rhino.Compute, the server version) is running. So both rhinoscriptsyntax and RhinoCommon live in the same world: they need Rhino. rhinoscriptsyntax is the easy front door; RhinoCommon is the full workshop behind it. In Grasshopper you will mostly use RhinoCommon, because the geometry you make flows straight back onto the canvas.

One detail trips people who move between the two: rhinoscriptsyntax usually works with object identifiers - references to things living in the Rhino document - while RhinoCommon works with the geometry objects themselves, whether or not they are in a document yet. That is exactly why RhinoCommon suits Grasshopper: on the canvas you are building geometry that may never be added to a Rhino file at all, just passed down the wires. It is also why the same word, say a curve, can feel different in each library - in rs it is often an id you pass around, in RhinoCommon it is a Curve object with methods like GetLength() and PointAt() you call directly. When an AI assistant or a forum answer mixes the two styles, this is usually the source of the confusion. If code from the internet does not run, checking whether it expects object ids (rhinoscriptsyntax) or geometry objects (RhinoCommon) is one of the first things to try, and it resolves a surprising share of copy-paste failures.

Now the surprising world. rhino3dm is a small, open-source, freely installable library - pip install rhino3dm - that runs anywhere Python does, with no Rhino present. What it gives you is the ability to read and write the .3dm file format and work with geometry as data: create points, lines, curves, meshes and breps, put them on layers, set attributes, and save a valid Rhino file.

import rhino3dm

model = rhino3dm.File3dm()
model.Objects.AddPoint(0, 0, 0)
model.Objects.AddLine(
    rhino3dm.Point3d(0, 0, 0),
    rhino3dm.Point3d(10, 0, 0),
)
model.Write("out.3dm", 7)   # 7 = the file version to save

That script produces a real .3dm on a machine that has never seen Rhino. The essential limitation is the flip side of its portability: rhino3dm has no geometry kernel. It can hold a surface and a curve as data, but it cannot trim the surface with the curve, cannot boolean two solids, cannot loft. Those operations need the kernel, which lives only inside Rhino or Rhino.Compute. rhino3dm is a container and constructor, not a modeller. Think of it as the library that lets a script, a website or a data pipeline touch Rhino files without a Rhino licence.

rhino3dm is also refreshingly ordinary as Python. Once a .3dm is open, its contents are just collections you iterate with the same loops from Module 2 - for obj in model.Objects: walks every object, model.Layers is a sequence of layers, and each object carries geometry and attributes you can read like any other data. Because it installs with pip and needs nothing else, it slots naturally into the file-and-folder automation of Module 8: read a model, pull some numbers, write them to a CSV, move on to the next file. The library also exists for JavaScript and C#, so a design tool you build can share the exact same understanding of a Rhino file across a web front end and a Python back end - a genuinely powerful thing for a small practice building its own tooling.

The decision is really one question: where does my code run? If it runs inside Rhino or a Grasshopper script component, and especially if you need to actually model - trim, offset, boolean - use rhinoscriptsyntax for quick tasks or RhinoCommon for real work. If it runs outside Rhino - a batch job over a folder of files, a web service, an automated export - and you only need to read, generate or rearrange geometry as data, use rhino3dm.

A classic rhino3dm job is auditing a folder of models without opening a single one:

import rhino3dm

model = rhino3dm.File3dm.Read("tower.3dm")
print("objects:", len(model.Objects))
for layer in model.Layers:
    print("layer:", layer.Name)

That runs in a fraction of a second, on any machine, over any number of files in a loop - the kind of automation Module 8 builds on. If you later need to change geometry with real modelling operations, that is the moment to move the work inside Rhino, or to call Rhino.Compute, a headless server that exposes the kernel over the web so even a remote script can trim and loft. For most designers, the practical map is simple: model inside Rhino, wrangle files outside with rhino3dm.

It helps to see the .3dm file as the neutral ground both worlds share. A Grasshopper definition using RhinoCommon can bake geometry into a Rhino document and save it; a standalone rhino3dm script on another machine can then open that same file and read it as data - no shared code, just a shared format. This is how a pipeline is often stitched together in practice: designers model interactively in Rhino, an automated rhino3dm job picks up the saved files overnight to audit or export them, and if a genuine modelling step is needed in that pipeline, a Rhino.Compute call fills the one gap rhino3dm cannot. Knowing which of the three you need for a given line of code - and it really is just those three - is most of what this lesson is teaching.
