Data Trees & Grasshopper Logic

Start from what you know. A Python list is a flat, ordered run of items - [a, b, c, d] - one after another, no grouping. A Grasshopper data tree is a step up: it holds several lists at once, each kept in a separate branch, and every branch has an address called a path, written in braces like {0;0} or {1;2}.

So where a list is one line of items, a tree is a set of labelled lines:

{0;0}  ->  [a, b, c]
{0;1}  ->  [d, e]
{1;0}  ->  [f]

The whole point of the branches is that structure carries meaning. If each branch is one floor of a building, the tree keeps every floor's columns grouped and labelled by floor - lose the tree and you have one anonymous pile of columns with no idea which belongs where. In Python terms, a tree is closest to a list of lists (or a dictionary keyed by path), and that is exactly how you will handle it in code. The reason Grasshopper uses trees rather than flat lists everywhere is that design data is naturally grouped: panels per facade, rooms per floor, points per curve. The tree remembers the grouping; a flat list forgets it.

The path notation rewards a second look, because the semicolons are not decoration. A path like {0;1} describes a position in a hierarchy: think of it as folder 0, subfolder 1 - trees can nest several levels deep, just as a project nests building, floor, room. Most everyday work stays one or two levels deep, but knowing the path is an address with levels explains why some components add a level (grafting) and others remove one (flattening). When Grasshopper shows you {0;0}, {0;1}, {1;0} in a Panel, it is simply listing the addresses of the branches it is holding - read them like a table of contents for your data, and the tree stops feeling opaque.

Two operations reshape trees constantly, and understanding them cures most Grasshopper confusion. Flatten collapses every branch into a single one - it throws the grouping away and gives you one long list. Graft does the opposite - it pushes each item down into its own new branch, so a list of three becomes three branches of one.

Why does this matter so much? Because Grasshopper components match items between inputs by their tree structure. Give a Line component ten start points in one flat branch and ten end points in one flat branch, and it draws ten lines, pairing them in order. But give it ten start points flat and end points grafted into ten separate branches, and the matching goes haywire - you get a tangle, because the shapes do not correspond. The infamous moment when almost right but weirdly duplicated geometry appears is nearly always a flatten-versus-graft mismatch between two inputs.

The practical skill is to picture the tree shape of each input and make them correspond. Two inputs that should pair item-for-item need matching structures. When they do not line up, the fix is usually a Flatten, a Graft or a Simplify on one side - not more components, just the right reshaping. Seeing data trees is, more than anything, the Grasshopper skill.

A concrete example makes the matching rule stick. Suppose you have three rooms, each with its own list of furniture points, held as a tree of three branches, and you want to move each room's furniture by that room's own offset vector. If the points are a tree of three branches and the vectors are a flat list of three, the shapes do not correspond and the Move component will misbehave. Graft the three vectors so each sits in its own branch, and now branch {0} of points meets vector {0}, branch {1} meets vector {1}, and everything lines up. The lesson generalises: when you want per-group behaviour, make the group structures match. That single instinct - look at both trees, make them correspond - resolves the overwhelming majority of Grasshopper mysteries without a line of code.

When you set a script component input to Tree access (lesson 6.1), your code receives the whole structure as a DataTree object, and you can walk it branch by branch. The pattern is to loop over the tree's paths and pull each branch as a list:

# x set to Tree access -> x is a DataTree
totals = []
for i in range(x.BranchCount):
    branch = x.Branch(i)      # this branch as a list
    totals.append(sum(branch))
a = totals

That sums each branch independently - one total per floor, say - which is exactly the kind of per-group operation trees exist for. To build a tree to send back out, you create a DataTree and add items at chosen paths:

from Grasshopper import DataTree
from Grasshopper.Kernel.Data import GH_Path

tree = DataTree[object]()
for i, row in enumerate(grid):        # grid is a list of lists
    for value in row:
        tree.Add(value, GH_Path(i))   # branch i gets this row
a = tree

Here every sublist of grid becomes its own branch {i} - you are grafting-by-construction. This is the honest picture of trees in code: a DataTree on the Grasshopper side maps neatly onto a list of lists on the Python side, and Branch(i) and GH_Path(i) are how you cross between them. Most of the time you convert the tree to nested lists, do ordinary Python, and convert back.

That convert-work-convert rhythm is the single most useful habit for tree scripting, and it keeps your code readable. Rather than fighting DataTree methods throughout, many people write a tiny helper that turns a tree into a plain list of lists at the top of the script, do all their thinking in ordinary Python where every skill from Modules 2 and 3 applies, then rebuild a DataTree only at the end for the output. The enumerate in the build example is doing real work: it pairs each sublist with its index i, and that index becomes the branch path, so the output tree mirrors the structure of your Python nesting. Keep the two pictures aligned in your head - branch equals list, path equals index - and moving data across the boundary stops being fiddly.

So when should you drop into a script for tree work, and when should you stay visual? An honest guide, because both extremes waste time.

Code tends to win when the logic is genuinely complex: multi-level conditionals, iteration where each step depends on the last, custom matching rules, or reshaping that would take a long, unreadable chain of Tree components. In a script you can loop over branches, use ordinary Python if and for, and express the intent directly - a paragraph of code instead of twenty tangled components.

Components tend to win for the ordinary flow: standard reshaping (a single Flatten, Graft or Path Mapper), anything you want to see and tweak visually, and work others must read and edit - a wired definition is often more legible to a collaborator than a dense script. Components also give live preview at every step, which is invaluable while you are still finding the shape of a problem.

The mature answer, as in lesson 6.1, is both: reshape and flow with components, and drop a script component in for the one knotty branch of logic that code expresses cleanly. Avoid the two failure modes - a heroic all-visual contraption straining to do what four lines of Python would, and a monolithic script that swallows work the canvas shows more clearly. Match the tool to the stretch, and let the tree structure - not habit - decide.

There is also a middle path worth knowing: you do not have to choose script-or-components for a whole definition, and you rarely should. The best Grasshopper users move fluidly - a Path Mapper here, a two-line script there, a Graft on one input - treating code as one more component that happens to be very flexible. A useful test when you are stuck is to ask, would I rather read this as a picture or as a sentence? Reshaping and flow are pictures; conditional rules and iteration are sentences. Answer honestly for the stretch in front of you and the right tool usually names itself. Over a career, this judgement - not memorised syntax - is what makes someone quick and reliable in Grasshopper, and it is the note this module ends on.
