Unit IIArchitectural Design IX

Reading & Analysing the Site

Survey before plan — and the brief you find in the analysis.

≈ 50 min + studio task

An urban design proposal is only as good as the reading behind it. Learn the urban survey across its layers; context models and SWOT; Patrick Geddes's two enduring lessons — survey before plan and conservative surgery; and the discipline of deriving the brief from the analysis — the brief is found in the site, not assumed.

Learning objectives

By the end of this lesson, you will be able to — mapped to the course outcomes for Architectural Design IX:

1
CO2 · Analyse

Survey an urban site across physical, social, environmental, movement and regulatory layers.

2
CO2 · Apply

Build context models and a SWOT synthesis of the site.

3
CO2 · Understand

Explain Geddes's 'survey before plan' and 'conservative surgery'.

4
CO2 · Analyse

Derive the design problem and brief from the analysis.

Read the whole site

The urban survey

Survey the site in layers — physical, social, environmental, movement, land use and byelaws — then synthesise them, with a context model and a SWOT, into one design-driving reading.[1, 2]

The survey layers Physical / built form Socio-economic Environmental / ecology Transport / movement Land use + byelaws Each layer is a drawing; overlaid, they reveal the site's logic — and its problems.
DiagramThe urban survey reads the site in layers — physical, socio-economic, environmental, transportation, land use and byelaws

Read the whole site

A thorough urban survey reads the site in layers: PHYSICAL/built form (figure-ground, heights, frontage, condition, landmarks); SOCIO-ECONOMIC (who lives and works here, activities, informality); ENVIRONMENTAL/ECOLOGICAL (drainage, microclimate, green and blue networks, ecosystem services); TRANSPORTATION/MOVEMENT (pedestrian, cycle, transit, vehicle, parking); LAND USE; and BYELAWS / development control (FSI, setbacks, coverage, height limits, heritage controls). Each layer becomes a drawing; overlaid, they reveal the site's logic and its problems.[1, 2]

Survey before plan

Geddes & the brief

Geddes insisted on understanding a place before proposing for it, and on conservative surgery — mending dense old quarters rather than clearing them; the brief is then derived from what the survey reveals.[2, 3]

Conservative surgery vs clearance Conservative surgery opened fabric & community kept Wholesale clearance everything demolished community displaced Geddes intervened minimally and surgically — open just enough for light, air and a path. The ethical heart of intervening in a living Indian city — and the ancestor of adaptive reuse.
DiagramGeddes's conservative surgery opens just enough in a dense old quarter and keeps the fabric, against wholesale clearance

Geddes's first lesson

Patrick Geddes (1854–1932), in Cities in Evolution (1915), insisted on SURVEY BEFORE PLAN — observe, document and understand a place before proposing anything. Working in India from 1914, he wrote some fifty town-planning reports (Indore, Madurai, Baroda, Lucknow, among others), reading each city on foot. MISCONCEPTION→correct: 'analysis is a throwaway prelude to the real design' — for Geddes the brief is DERIVED from the survey; skip the reading and you design the wrong thing well.[3]

The brief is found, not assumed SURVEY read the site ANALYSIS SWOT · synthesis THE BRIEF the design problem, named A brief imposed on the site — not found in it — is indefensible at jury. A severed link, a dead frontage, a neglected riverbank — the site names its own problem.
DiagramThe design brief is derived from the survey and analysis — not assumed before seeing the site
Surgery vs clearance

At a glance

AspectConservative surgeryClearance
ApproachConservative surgery: mend & retainClearance: demolish & rebuild
FabricLargely keptLost
CommunityStays in placeDisplaced
Cost & riskLower, incrementalHigh, disruptive
Brief comes fromThe survey (found)Assumption (imposed)
Vocabulary

Key terms

Urban survey

Layered documentation — physical, social, environmental, movement, land use, byelaws.

Context model

A physical/digital 3D model of the site and its surroundings.

SWOT synthesis

Strengths, weaknesses, opportunities, threats — distilling the analysis.

Survey before plan

Geddes's principle: understand a place before proposing for it.

Conservative surgery

Minimal, sensitive intervention that retains fabric and community.

Deriving the brief

Naming the design problem from the site's analysis, not assumption.

Apply it

Studio task

For a site you can visit, prepare four quick survey drawings — built form, movement, environment/green, and land use with byelaw constraints — and a short SWOT. From them, write a one-sentence design PROBLEM statement that is clearly DERIVED from the analysis (a severed link, a dead frontage, a neglected edge). Then say whether conservative surgery or larger redevelopment fits, and why.

Check your understanding

Self-assessment

1. Patrick Geddes is best known in urban design for —

2. 'Conservative surgery' means —

3. In the studio, the design brief should be —

In a nutshell

Recap

Survey the site in layers — physical, social, environmental, movement, land use and byelaws — one drawing each.
A context model and a SWOT synthesis turn many layers into a clear, design-driving reading.
Geddes's 'survey before plan': understand a place before proposing for it.
'Conservative surgery' mends dense old quarters minimally, retaining fabric and community — not clearance.
Derive the brief FROM the analysis — a problem found in the site is defensible; one imposed on it is not.
The evidence

References & further reading

  1. [1]Carmona et al., Public Places — Urban Spaces — survey, analysis and the morphological/functional dimensions.
  2. [2]Kevin Lynch & Gary Hack, Site Planning (3rd ed., MIT Press, 1984) — reading and arranging the site.
  3. [3]Patrick Geddes, Cities in Evolution (1915) + Indian town-planning reports — survey before plan, conservative surgery.
  4. [4]URDPFI Guidelines 2014 (MoUD, India) — survey content, development control and the planning framework.

Further reading

  • Kevin Lynch & Gary Hack — Site Planning.
  • Patrick Geddes — Cities in Evolution.
  • Carmona et al. — Public Places Urban Spaces.
