Unit IIWorking Drawings & Detailing

Architectural Working Drawings

Centre-line dimensioning that adds up — and schedules that tabulate

The architectural working drawing sets out the building for construction, and this unit is about getting the numbers right. Plans are dimensioned to a consistent reference — usually wall centre-lines — and the golden check is that the chain of dimensions must add up to the overall, or the drawing gives the builder two different answers. You never dimension the same thing twice, because over-dimensioning plants conflicts. And repetition is handled with a schedule: doors and windows keyed by type and tabulated once, not annotated at every opening.

Learning objectives

By the end of this lesson, you will be able to — mapped to the course outcomes for Working Drawings & Detailing:

1
CO2 · Understand

Explain centre-line drawing and dimensioning and why walls are dimensioned to centre-lines or a consistent face.

2
CO2 · Apply

Build a dimension string that reconciles to the overall, and avoid over-dimensioning.

3
CO2 · Apply

Prepare a door and window (joinery) schedule that tabulates openings by type.

A consistent reference

Centre-line dimensioning

Plans are dimensioned to a consistent reference — usually the centre-lines of walls and columns (the structural setting-out). What matters is holding that reference throughout: mixing centre-line and face dimensioning in one string is a classic error that stops the numbers adding up.[1, 2]

Centre-line dimensioning measure to the axis, not the shifting face 3300 dimension to centre-lines mixing centre-line and face dimensions two datums, one wrong wall pick one system and dimension to the centre-lines
DiagramA plan dimensioned to wall centre-lines, with mixing centre-line and face dimensioning struck out

Dimension to a consistent reference

Architectural plans are dimensioned to a CONSISTENT reference — usually the CENTRE-LINES of walls and columns, sometimes a chosen face — so the numbers describe the structural setting-out, not just the surface. Centre-line dimensioning suits masonry set out about an axis; face dimensioning suits finished openings. What matters is CONSISTENCY: pick the reference and hold it throughout, because mixing centre-line and face dimensions in one string is a classic error that makes the numbers stop adding up.[1, 2]

The segments must add up

Try it — the dimension-string checker

The golden check made interactive. A wall is a fixed overall width; adjust the three bays and watch whether the chain of figured dimensions reconciles to the overall (green) or conflicts (red). A string that doesn’t total the overall gives the builder two different answers.

Dimension-string checker · the segments must add up to the overall

This wall is a fixed 4200 mm overall. Adjust the three bays — the chain of figured dimensions must total the overall, or the drawing gives the builder two different answers.

OVERALL 42001500Bay A1200Bay B1500Bay C
Bay A1500
Bay B1200
Bay C1500

Bays total 4200 mm vs overall 4200 mm

Reconciles

A string whose parts don’t sum to the overall gives two conflicting instructions. And you build to these figures — never by scaling the drawing.

The string must add up running dimensions must reconcile with the overall GOOD 4200 1500 1200 1500 1500 + 1200 + 1500 = 4200 reconciles BAD 4200 1500 1500 1500 1500 + 1500 + 1500 = 4500 does not add up
DiagramThree bay dimensions 1500, 1200, 1500 totalling the overall 4200 with a green tick, beside a version summing to 4500 struck out in red as not adding up

Over-dimensioning is a fault

'More dimensions is safer' is a MYTH. Dimension each thing ONCE, from a logical datum. Give the same distance twice and, after any edit, the two figures will disagree — and the builder cannot tell which is correct, so a well-meant 'safety' dimension becomes a defect. Good dimensioning is COMPLETE (every needed size is given once) but not REDUNDANT (no size given twice). Keep dimension lines clear of the object, group them in tidy strings, and let each figure appear in exactly one place.[1]

Tabulate, don't annotate

The joinery schedule

Doors and windows are handled with a schedule, keyed by type (D1, W2) and tabulated once — fifty identical doors become one row referenced fifty times. It keeps the plan clean and makes a change a one-line edit — provided the plan tags and schedule rows always agree.[1, 3]

Dimension once every dimension repeated is a chance to disagree 900 one figure, from a datum 900 910 "more is safer" — they disagree dimension once, from a datum
DiagramA door opening dimensioned once as 900, beside the same opening dimensioned twice with conflicting 900 and 910 struck out in red
The joinery schedule draw the door once, list it by type Type Size Material Finish D1 D2 W1 900 × 2100 750 × 2100 1200 × 1200 teak . . . flush . . . UPVC . . . polish paint glazed D1 D1 D2 tabulate repetition by type tags reference the schedule
DiagramA drawn door schedule table keyed D1, D2, W1 by size, material and finish, referenced by matching tags on a small plan
Standards on the plan the marks that make a plan a plan 1 2 A B door swing N +0.000 level marker 0 1m scale bar the plan carries the standards
DiagramA plan corner showing standards in use: a north point, scale bar, grid lines, a door swing and a level marker

Tabulate, don't annotate

Doors and windows are handled with a SCHEDULE, not by annotating every opening. Each opening is keyed by TYPE — D1, D2, W1 — and the schedule tabulates each type's size, material, finish, glazing and ironmongery once. Fifty identical doors become one schedule row referenced fifty times on the plan. This keeps the plan clean, puts the information in one place, and makes a change (say, a finish) a one-line edit instead of fifty. The plan tags and the schedule must always agree.[1, 3]

Fact vs folklore

At a glance

AspectThe factThe folklore
Plans are dimensioned toA consistent reference — usually wall centre-linesWhatever is convenient, mixed
A dimension string mustADD UP to the overall dimensionLook roughly right
Dimensioning the same size twiceA fault — the two will disagree after editsSafer
Good dimensioning isComplete but not redundant — once, from a datumAs many dimensions as possible
Doors and windows areScheduled by TYPE (D1, W2), tabulated onceAnnotated at every opening
A schedule works only ifThe key is exact — every tag matches its rowIt looks complete
Vocabulary

Key terms

Centre-line dimensioning

Dimensioning to the centre-lines of walls and columns (the structural setting-out), held consistently; mixing centre-line and face dimensions makes a string stop adding up.

Dimension string reconciliation

The rule that a chain of segment dimensions must add up to the overall dimension; running and chain dimensions must agree, or the drawing gives conflicting sizes.

Over-dimensioning

Dimensioning the same distance more than once — a fault, not thoroughness, because the copies disagree after edits; dimension each thing once from a datum.

Joinery (door/window) schedule

A table keying every door and window by type to its size, material, finish and ironmongery, so openings are tabulated once instead of annotated everywhere.

Schedule key

The type code (D1, W2) linking a plan tag to its schedule row; it must be exact and unique, or the schedule and plan cannot be read together.

Setting-out

Fixing the position of walls and structure on the plan by dimensions from a datum and grid — the base the interior and services layouts all reference.

Apply it

Study task

Draw the dimensioned plan of a two- or three-room flat. Dimension it to a consistent reference (centre-lines), give both the segment (chain) and the overall dimensions, and prove that every string adds up to its overall — write the sum in the margin as a check. Make sure nothing is dimensioned twice. Add the standards: a north point, a scale bar, grid lines and floor levels. Finally, prepare a door and window schedule keyed by type, and tag every opening on the plan to match its schedule row exactly. The test is that a builder could set the plan out from your figures alone, with no string that fails to reconcile and no opening whose tag and schedule disagree.

Check your understanding

Self-assessment

1. To what reference are architectural plans usually dimensioned?

2. What must a chain of dimensions always do?

3. Why is dimensioning the same distance twice a fault?

4. How are doors and windows documented?

5. A schedule only works if what is true?

In a nutshell

Recap

Architectural plans are dimensioned to a CONSISTENT reference — usually wall centre-lines — held throughout; mixing centre-line and face dimensions breaks the string.
A chain of dimensions must ADD UP to the overall — running and chain dimensions must reconcile, or the drawing gives the builder conflicting sizes.
Dimension each thing ONCE from a datum — over-dimensioning is a fault, because duplicated figures disagree after edits and the builder can't tell which is right.
The plan carries the STANDARDS — symbols, north point, scale bar, grid and levels (IS 962) — and is the base the interior and services layouts reference.
Doors and windows are SCHEDULED by type (D1, W2), tabulating repetition once; the plan tags and schedule rows must always match on an exact key.
The evidence

References & further reading

  1. [1]Architectural working drawings — centre-line dimensioning, reconciling dimension strings, avoiding over-dimensioning, and joinery schedules (Ernst Neufert, Architects' Data; Interior Graphic Standards). https://www.wiley.com/
  2. [2]IS 962:1989, Code of Practice for Architectural and Building Drawings — dimensioning, symbols, grids and standards on plans (BIS). https://www.bis.gov.in/
  3. [3]Door and window (joinery) schedules — tabulating openings by type with size, material, finish and ironmongery (drawing-office practice; McGowan & Kruse, Interior Graphic Standards). https://www.wiley.com/

Further reading

  • Ernst Neufert, Architects' Data.
  • Maryrose McGowan & Kelsey Kruse, Interior Graphic Standards.
  • Mark W. Lin, Drawing and Designing with Confidence.

Sources gathered and fact-checked June 2026. Published values vary by source, sample and method — treat as indicative and confirm against the cited standard before structural use.
