Lesson 5.2Lesson 5.2 · Designing With the Constraint
The Vastu-Audit Worksheet
The one page that turns a Vastu conversation into a plan everyone can read, argue with, and sign off.
Six columns beat six arguments
You leave the kitchen-table meeting with eleven Vastu requirements and a head full of half-decided compromises. Three weeks later, on site, the mason asks where the cooking platform goes — and nobody can remember what you agreed, or why. The audit worksheet exists so that conversation only happens once, on paper, where everyone can see the reasoning.
One row, one rule, one verdict
The Vastu audit worksheet is a single table. Every Vastu requirement the client raises in the 5.1 conversation gets exactly one row — and that row is not finished until it carries its own verdict. This is Module 0's core discipline, finally operationalised: one good rule never vouches for the rest. The south-east kitchen earning its keep does not buy the lucky-number rule a free pass. Separate rows force separate judgements.
Read the six columns left to right and you have rebuilt the tool: (1) The rule, in the client's own words — "the kitchen must be in the south-east," not your paraphrase, because the client has to recognise their belief in the document. (2) The physical claim underneath — ask "what would an instrument detect here?" A thermometer? A lux meter? Nothing measurable? Some rows have a real claim; many have none, and writing "none" is itself an honest finding.
(3) The bucket — 🟢 climate logic, 🟡 plausible-but-contingent, 🔴 convention — assigned from columns 1 and 2, never from the client's certainty. (4) Depends on — the site and technical conditions that decide the bucket, drawn straight from Modules 1–3: orientation, climate zone, plot slope, hob type, glazing area. (5) The action — Honour free / Translate to intent / Satisfy cheaply / Hold the line. (6) Cost & priority — free, low-cost-symbolic, design-budget, or a real trade-off you must flag aloud.
The colour of a row tells you what kind of conversation it is
Once the rows are sorted, the worksheet stops being a checklist and becomes a map of the project's negotiations — and each colour means a different kind of talk.
Green rows are gifts. The north-east kept open and low, the heavy mass to the south-west, the morning light into the prayer and breakfast zones — these are sound passive-design moves in most of the Indian climate. Honour them for free and, crucially, tell the client why they also serve comfort and energy. The green rows often are your passive-design strategy; the tradition did the climate analysis for you.
Yellow rows are where the design actually happens. "South-east kitchen" is yellow because its merit depends on hob type, glazing and cross-ventilation (Module 2). Here you translate to intent: honour the underlying goal — keep heat and smoke away from living and sleeping zones — with a hood, an openable window and a sensible layout, even if the compass bearing shifts a few degrees. Yellow rows generate your real trade-offs and most of your billable design thinking.
Red rows are beliefs, and you respect them cheaply. A lucky house number, an avoided room name, a threshold ritual — satisfy them with symbolic, low-cost gestures and never let them spend the performance budget. Which brings us to the worksheet's quiet financial discipline.
A red row costs a brass nameplate. A green row costs nothing and pays you back every afternoon. Price them honestly and the client sees it too.
The belief budget: a ring-fenced line item
Carry forward 4.2's ledger and give it a home on the worksheet. Total the cost column for every 🔴 red row and write it as a single, explicit line: the belief budget. A nameplate, a tulsi placement, a colour for an east wall, a small puja niche — sum them and show the figure.
The point of naming it is protection. When the belief budget is a visible, ring-fenced line, it can be respected generously and still never bleed into the performance budget — the structure, the waterproofing, the insulation, the glazing that actually keep the house standing and comfortable. The client sees that you took their faith seriously enough to budget for it, and sees just as clearly that you refused to let a colour preference compromise a beam.
Fill the worksheet live in the 5.1 meeting wherever you can. Rows written in front of the family, with the consultant in the room, settle disputes before they reach the site. The finished sheet is a shared document: client, family and any Vastu consultant can all read the same reasoning, in plain language, with the physics and the costs in the open. That transparency is what turns "Vastu versus design" into one aligned plan.
Studio Matrx offers a printable Three-Bucket / audit worksheet as the course download — but the tool is the habit, not the PDF. Sketch the six columns on the back of a site drawing and it still works.
How each rule sorts
The worksheet's own disciplines — and the habit that quietly defeats it.
Separate judgement defeats the halo effect: a rule with real climate merit cannot lend its credibility to an unrelated convention. Each row is assessed on its own evidence, which is Module 0's discipline made repeatable.
An explicit, capped line item lets you honour conventions cheaply while protecting structure, waterproofing and glazing spend. The 4.2 ledger becomes a single visible number nobody can quietly raid.
Unrecorded verdicts drift: the halo effect creeps back, decisions contradict each other, and the site team improvises. Nothing physical fails — but the project does, through inconsistency and on-site surprises.
What the worksheet actually does
- Six columns force every rule past the same questions: what is claimed, can an instrument detect it, what does it depend on, what will we do, what will it cost.
- Green rows are usually free passive design; yellow rows are where you negotiate and bill; red rows are cheap, respected belief.
- A ring-fenced belief budget honours faith generously while protecting the performance spend from it.
- One shared, plain-language sheet aligns client, family and consultant — and kills the mid-project on-site surprise.
In 5.3 we put the worksheet to work on three real plans — a tight urban plot, a sloping site, and a kitchen that simply cannot face south-east — and watch the same six columns reconcile each one without drama.
