Fire & Compartmentation in Modular

Start with the geometry, because the fire problem follows directly from it. A volumetric module is a closed box - it has its own four walls, its own floor and its own ceiling, all finished in the factory. When you place one box beside another, two walls sit face to face with a small construction and erection gap between them. When you stack one box on another, the floor cassette of the upper module sits above the ceiling of the lower, again with a gap. So at every vertical joint you get a double wall with a cavity, and at every horizontal joint a double floor-and-ceiling with a void between them. A site-built building simply does not have these doubled layers and the continuous cavities they create.

These cavities are not a defect; they are how modular goes together. The gap gives erection tolerance so modules can be craned into place without jamming, it carries the structural connections, and it often routes services. But a concealed cavity is exactly the environment a fire loves: oxygen, a path, and no one watching. Fire and hot smoke entering a continuous void can travel laterally and vertically behind the finishes, bypassing the rooms entirely, and emerge in a module far from the origin - the classic concealed-space fire spread that has driven so much fire regulation. The danger is that the building looks compartmented (solid-seeming walls and floors everywhere) while the voids quietly connect everything.

There is a second subtlety. Because the module is finished in the factory, much of its fire-resisting lining - plasterboard layers, intumescent coatings, encasement - is installed and inspected at the bench, which is genuinely good for quality. But the joint between modules is completed on site, in the very cavity that is hardest to reach once the next module lands on top. The part of the fire-resisting system that is most critical to concealed-space spread is therefore often the part assembled last, in the worst conditions, by whoever is left to close the gap. Recognising that inversion - factory-good linings, site-completed joints - is the beginning of designing modular fire safety honestly.

Compartmentation is the strategy of dividing a building into fire-resisting cells - compartments - so that a fire is held within its cell for a defined period (the fire-resistance rating, expressed in minutes), giving people time to escape and firefighters time to act. A compartment only works if its boundary is continuous: an unbroken line of rated construction all the way around, with every wall, floor, door and penetration in that line performing for the required period. One weak point - an unsealed gap, a poorly stopped penetration - and the compartment leaks.

In modular construction the compartment lines keep crossing module boundaries, which is where the principle gets hard. A party wall between two flats may be formed by the two module walls meeting at a joint; a compartment floor between storeys may be formed by the upper module's floor over the lower module's ceiling. The fire-resistance rating that each individual wall or floor achieves in a laboratory test is not the question. The question is whether the assembled junction - wall-to-wall, floor-to-wall, module-to-module corner - still delivers that rating once the real gap, the structural connection and the services are all present. A rated element with an unsealed cavity running past it is not a compartment boundary; it is a rated element with a hole beside it.

So the design discipline is to treat every module interface as a place where a compartment line must be deliberately re-made, not assumed. Where does the compartment line run? Which module faces form it? How is the cavity at that line closed so the line is whole? How do the horizontal and vertical compartment lines meet at a corner where four module edges come together - the hardest detail in the building? These are questions to raise at concept, because the answers shape the module layout itself: you want compartment lines to fall on clean module boundaries, not to wander diagonally through a module where they are almost impossible to form. None of the specific answers - ratings, detail geometry, test evidence - are yours to set. They come from the fire engineer and the manufacturer's tested system. But framing the module grid so that compartmentation is achievable is very much a design decision, and a bad grid can make good fire detailing nearly impossible.

If the voids are the problem, the principled answer is to stop fire and smoke from using them - and the two tools for that are cavity barriers and fire-stopping, which are related but not the same. A cavity barrier is a construction placed within a concealed cavity to close it off and sub-divide it, so that fire entering the cavity cannot run freely along its whole length - it turns one long continuous void into short, bounded compartments of void. Fire-stopping is the sealing of a specific gap or penetration - the linear joint between two elements, or the hole where a pipe or cable passes through a rated construction - so that the gap itself resists fire for the required period, using tested products such as intumescent sealants, mineral-wool packing, collars and wraps that expand or hold back heat and smoke.

In a modular building, cavity barriers are placed to break up the continuous vertical and horizontal voids at module boundaries - typically at the perimeter of each module and at compartment lines - so that the double-skin cavities cannot act as chimneys connecting module to module. The double-skin joint itself, where two module faces and their cavity meet a compartment line, must be fire-stopped so the line is continuous across it. The hard truth is practical: much of this work happens in the very gap that becomes buried and inaccessible the moment the next module is placed. So the sequence matters enormously - which barrier and seal goes in at the factory, which is fitted on site before the adjacent module lands, and who inspects the closed joint before it disappears forever. A missed cavity barrier in a site-built wall can sometimes be retrofitted; a missed one between two stacked modules may be unreachable.

This is why modular fire-stopping is a design-and-sequencing problem as much as a product problem. The position of every barrier, the products used, their tested performance, and the installation and inspection regime are all set by the fire engineer and the manufacturer's tested detail - never improvised. Your contribution is to understand that these voids exist, to insist they are addressed at design stage rather than discovered on site, and to protect the access and sequence that let them be installed and checked. Ask early: where are the cavity barriers, who fits them and when, and how is the closed joint inspected before it is covered?

The third big fire variable in modular is the material of the system itself. Structural modular systems run broadly from non-combustible (light-gauge steel frame, structural steel, precast concrete) to combustible (timber and mass timber such as cross-laminated timber). This distinction matters enormously for fire, because a combustible structure can itself contribute fuel and can be involved in the fire in ways a steel or concrete frame is not, and because regulations in many jurisdictions restrict or prohibit combustible construction above certain heights or in certain uses - rules that have tightened significantly in several countries after major fires.

This is emphatically not a reason to treat timber modular as unsafe or steel and concrete as automatically safe. Mass timber can be engineered to perform predictably in fire - it chars at a known rate, and the design can size members to retain structural capacity for the required period - and there are fine, code-compliant tall timber buildings. Equally, a non-combustible frame still needs proper compartmentation, cavity barriers and fire-stopping; its frame will not burn, but an unsealed void in a steel-framed module spreads fire and smoke just as readily. The material changes the fire engineering; it does not remove it. And the full picture includes more than the structure - the surface spread of flame of internal linings, the combustibility of insulation and of external wall build-ups, and the protection of escape routes all sit inside a single coherent fire strategy.

Here is where your judgement must stop and the specialists' must take over. Whether a given combustible or non-combustible system is permitted for this building's height and use; what fire-resistance period applies; how the structure, compartmentation, linings, insulation, cladding and escape strategy combine into a compliant whole - all of this is binding fire engineering governed by the National Building Code of India and local regulations, resolved by a qualified fire engineer working with the manufacturer's tested system and its approvals. Treat any rating, char rate or height limit in a course like this as illustrative of a principle, never as a specification. The design skill you are building is to know that the material choice has profound fire consequences, to bring the fire engineer in at the very start (because it shapes the system choice and the grid), and never to assume that because a module arrives finished, its fire safety is finished too.
