The Documentation Report
Assembling and presenting the record
The study becomes an architectural report — an ordered, analysed account of the five aspects, not a scrapbook. Documentation photography serves the record, not flattery: systematic coverage, true verticals, a scale reference, context and detail. And the study is presented — as a report, a slideshow and a video — clearly enough that someone who never saw the building understands it. In the end, field study is the discipline of truly seeing a building, and preserving what you saw.
Learning objectives
By the end of this lesson, you will be able to — mapped to the course outcomes for Field Study & Documentation:
Assemble sketches, photographs and drawings into an ordered documentation report.
Photograph a building for the record — systematic, controlled and honest.
Present the study clearly as a report, a slideshow and a video.
Assembling the report
The report assembles the study — introduction, history, drawings, photographs, analysis of the five aspects, conclusions, references — telling the building’s story and showing understanding. And documentation photography serves the record: systematic, controlled, honest, with true verticals and a scale.[1, 3]
An ordered, analysed account
The study becomes an architectural REPORT — an ordered, analysed account, not a scrapbook. A good report has a clear structure: an INTRODUCTION (the building and why chosen), the HISTORY and cultural context, the measured DRAWINGS (plans, sections, elevations, details), the PHOTOGRAPHS, the ANALYSIS across the five aspects, CONCLUSIONS, and REFERENCES. It tells the building's STORY and shows UNDERSTANDING, weaving the records into an argument about what the building is, how it works and how it is made. Structure, clear drawings and honest analysis are what turn raw survey material into real documentation.[1, 2]
Presenting the study
The study is presented — report, slideshow and video, each doing a job — clearly enough that someone who never saw the building understands it. And its deepest point is the discipline of truly seeing a building, and preserving what you saw — an education for you, and an act of conservation.[2, 1]
Report, slideshow, video
Finally the study is PRESENTED — as a written REPORT, a SLIDESHOW / presentation, and a VIDEO. Each medium does a job: the report holds the full, referenced record; the slideshow tells the story in sequence to an audience; the video walks through the building and brings its space and materials alive. Documentation that no one can follow has failed half its purpose. Present CLEARLY — a logical order, legible drawings, honest images, a clear narrative — so that someone who has never seen the building can understand it through your record. Communication is not a decoration on the study; it is how the understanding is shared. Try the five-aspect explorer as you plan.[2]
At a glance
| Aspect | The fact | The folklore |
|---|---|---|
| A documentation report is | An ordered, analysed account of the five aspects | A scrapbook of images |
| A good report shows | The building's story AND understanding | Only pretty pictures |
| Documentation photography | Systematic, controlled, honest — serves the record | Flattering and selective |
| It captures | Context AND detail, verticals true, with a scale | Only dramatic angles |
| Presentation media | Report, slideshow and video — each doing a job | One is enough |
| The point of it all | Truly SEEING a building — and preserving it | Filling a submission |
Key terms
The ordered, analysed architectural account of a field study — introduction, history, drawings, photographs, analysis of the five aspects, conclusions and references; not a scrapbook.
The logical order that turns records into documentation — from the building and why chosen, through history, drawings, photographs and analysis, to conclusions and references.
Systematic, controlled, honest photography that serves the record — full coverage, true verticals, even light, a scale reference, and both context and detail.
The report (the full referenced record), the slideshow (the story in sequence) and the video (a walk-through) — each communicating the study in its own way.
Presenting a study clearly so someone who never saw the building can understand it — not a decoration on the work but how the understanding is shared and preserved.
The dual gift of a field study — it teaches the designer to truly see, and it preserves a trace of a building that may change or vanish.
Study task
Assemble and present your field study as a complete documentation report. Structure it clearly — introduction (the building and why chosen), history and cultural impact, style and function, the measured drawings (plans, sections, elevations, details), the photographs, an analysis across the five aspects, conclusions and references. Make sure your documentation photography is systematic and honest, with true verticals and a scale reference, and shows both context and detail. Then present it — as the report, a short slideshow that tells the building’s story in sequence, and, if you can, a video walk-through. Finish by writing what documenting this building taught you about how to see. The test is a record someone who was never there can understand — your education, and a small act of conservation.
Self-assessment
1. What is a documentation report?
2. What is documentation photography?
3. Why present a study as report, slideshow AND video?
4. What is the deepest point of field study and documentation?
Recap
References & further reading
- [1]The architectural documentation report and record — structure, drawings, analysis and conservation value (Historic England, Understanding Historic Buildings; INTACH documentation guidance). https://historicengland.org.uk/
- [2]Communicating and presenting a study — report, drawings and presentation (Francis D.K. Ching, Architectural Graphics; presentation and architectural-communication references). https://www.wiley.com/
- [3]Architectural / documentation photography — systematic, controlled recording of buildings (architectural-photography references). https://www.nps.gov/hdp/
Further reading
- Historic England, Understanding Historic Buildings: A Guide to Good Recording Practice.
- Francis D.K. Ching, Architectural Graphics.
- INTACH heritage-documentation resources.
