Unit IIProject Management in Interior Design

Elements of a Network

Drawing the logic of a project — events, activities and dependencies

A bar chart shows timing; a network diagram shows the logic — which task must finish before which can start. It is built from activities (tasks that consume time, drawn as arrows) and events (instants, drawn as numbered nodes), with a dummy (a dashed, zero-time arrow) to carry a dependency. A valid network has one start and end, arrows from low to high numbers, and no loops. Spotting what can run in parallel is how a project is shortened without cutting any work.

Learning objectives

By the end of this lesson, you will be able to — mapped to the course outcomes for Project Management in Interior Design:

1
CO3 · Understand

Distinguish events, activities and dummies, and read a network diagram.

2
CO3 · Apply

Apply the rules for constructing and numbering a valid network.

3
CO3 · Analyse

Explain how a network shows dependencies a bar chart cannot, and why that matters.

Timing is not logic

Why a network — events and activities

A plain bar chart shows when; a network shows the dependencies a schedule must respect. It is built from activities (tasks that consume time, drawn as arrows) running between events (instants, drawn as numbered nodes). Keep the two straight: activities have duration; events simply mark moments.[1]

Anatomy of a network Circles are events; arrows are activities 1 2 3 4 Activity A Activity B Activity C Activity D KEY event (a milestone, no time) activity (work that takes time) A network shows how the activities of a project connect
DiagramThe anatomy of a network diagram: events as numbered circles and activities as arrows, with a key
Activities take time, events do not An event is an instant; an activity is the work in between 1 start event 2 A finished 3 all done Activity A wiring — 5 days Activity B plaster — 3 days Read it left to right: an activity uses days and resources; an event just marks the moment it starts or ends Activities cost time; events are the milestones they hit
DiagramA chain of events and activities: circle event one, activity arrow, circle event two, activity arrow, circle event three

Timing is not logic

A bar chart (Gantt) shows WHEN each task happens — its timing and duration — and it is the most readable schedule there is. But a plain bar chart does not show the LOGIC: which task must finish before which can start, and what depends on what. A NETWORK DIAGRAM does. It models the project as a connected picture of its DEPENDENCIES, so you can see the true sequence, find the critical path, and know what will slip if something is late. This is why network analysis underlies CPM and PERT. Timing and logic are different things: a schedule must respect the logic, and the network is where the logic lives.[1, 2]

Logic without work

The dummy activity

Sometimes the true logic needs a dummy — a dashed arrow of zero duration and resource. It is not real work; its only job is to carry a dependency or keep the network’s numbering valid. A small idea that trips many students: a dummy carries logic, not work.[1]

The dummy activity A dashed arrow that shows logic, not work REAL ACTIVITY 1 2 Activity A — 4 days solid line = real work, consumes time DUMMY ACTIVITY 3 4 Dummy — 0 days dashed = only a dependency, no work Why use one? To say “event 4 cannot start until event 3 is reached” it keeps the logic correct. A dummy adds a rule to the network, never a task to the schedule
DiagramA dummy activity drawn as a dashed zero-duration arrow enforcing a dependency, next to a solid real activity arrow

Logic without work

Sometimes the true logic of a project cannot be drawn with real activities alone, and you need a DUMMY. A dummy is drawn as a DASHED arrow, and it has ZERO duration and ZERO resource — it is not real work. Its only job is to show a DEPENDENCY, or to keep the network's logic and numbering correct (for instance, so that two activities do not share the same start and end events). It is a small idea that confuses many students, so hold it plainly: a dummy carries LOGIC, not work — it says 'this must wait for that', while itself taking no time and costing nothing. Reading dummies correctly is part of reading a network correctly.[1]

How a network must behave

The rules, and running in parallel

A valid network has one start and end, arrows from lower to higher numbers, and no loops (a project cannot depend on its own future). Serial activities wait in a line; parallel ones run at the same time — and spotting parallels is how a project is shortened without cutting any work.[1]

Rules of a valid network Number forward, no loops, one start and one end 1. NUMBER LOW → HIGH 1 2 arrows point to bigger numbers 2. NO LOOPS work can never flow back on itself 3. ONE START, ONE END S E everything fans out from S, back to E Break these rules and the network cannot be scheduled correctly Every arrow must move the project forward, from a single start toward a single finish.
DiagramRules for a valid network: numbered events, arrows low to high, and a looping arrow struck out in red as an error
Series vs parallel Running work in parallel shortens the schedule IN SERIES one after another, must wait A B A B total = A + B (long) IN PARALLEL independent, run together B C B C total = the longer one (short) Do independent tasks in parallel to finish sooner
DiagramActivities in series, one waiting for the next, versus in parallel, running at the same time to shorten the schedule

How a network must behave

A network follows RULES so it models the project truthfully. It has ONE start event and ONE end event. Every activity runs from a lower-numbered tail event to a higher-numbered head event, so time flows one way. There are NO LOOPS — a project cannot depend on its own future, so an activity can never lead back to an earlier event (that would be nonsense, and it is a genuine error, not a style choice). Two activities should not share the SAME pair of events (a dummy fixes this). Getting these rules right is what makes the network computable — only a valid network can be analysed for its critical path and float.[1]

Fact vs folklore

At a glance

AspectThe factThe folklore
A bar chart showsTiming — when and how longThe full dependency logic
A network showsThe LOGIC — what depends on whatOnly the timing
An activity isA task that consumes time and resource (an arrow)An instant in time
An event isAn instant — the start or finish of activities (a node)A task with a duration
A dummy activityCarries LOGIC only — zero time, zero cost (dashed)Real work that takes time
Parallel activitiesRun at the same time — how a project is shortenedMust always wait in a line
Vocabulary

Key terms

Network diagram

A model of a project as connected events and activities, showing the logical dependencies a schedule must respect — the basis of CPM and PERT.

Activity

A task that consumes time and resources, drawn as an arrow, running from a tail event (start) to a head event (finish).

Event

An instant in time — the start or finish of activities, a milestone — drawn as a numbered node; it has no duration or cost.

Dummy activity

A dashed arrow of zero duration and zero resource that carries only a logical dependency, or keeps the network's numbering valid — logic, not work.

Network rules

One start and one end event, arrows from low to high numbers, no loops, and no two activities sharing the same pair of events — what makes a network valid and computable.

Serial vs parallel

Serial activities happen one after another (each waits for the last); parallel activities are independent and run at the same time — spotting parallels shortens the project.

Apply it

Study task

Take a small interior job — say, refurbishing one room — and list about eight activities (survey, design, order materials, civil work, wiring, flooring, joinery, painting). For each, decide what must finish before it can start. Now draw the network: events as numbered circles, activities as arrows between them, obeying the rules (one start, one end, arrows low to high, no loops). Mark where you would need a dummy to carry a dependency without adding work. Then circle every pair of activities that could run in parallel rather than one after another — and note how much time that could save. The goal is to see a schedule as a structure of logic, not just a row of bars.

Check your understanding

Self-assessment

1. What does a network diagram show that a plain bar chart does not?

2. What is the difference between an activity and an event?

3. What is a dummy activity?

4. Why does spotting parallel activities matter?

In a nutshell

Recap

A NETWORK DIAGRAM models a project's LOGIC — the dependencies a schedule must respect — where a bar chart shows only timing.
An ACTIVITY is a task that consumes time and resource (an arrow); an EVENT is an instant, a start or finish (a numbered node) — keep them straight.
A DUMMY is a dashed arrow of zero duration and resource that carries only a logical dependency, or keeps the numbering valid — logic, not work.
A valid network has ONE start and end, arrows from low to high numbers, NO loops, and no two activities sharing the same pair of events.
SERIAL activities wait in a line; PARALLEL ones run at the same time — spotting parallels is how a project is shortened without cutting any work.
The evidence

References & further reading

  1. [1]B. C. Punmia & K. K. Khandelwal, Project Planning and Control with PERT and CPM — elements of network analysis: events, activities, dummies, and the rules for constructing and numbering a network. https://www.laxmipublications.com/
  2. [2]Jerome D. Wiest & Ferdinand K. Levy, A Management Guide to PERT/CPM, Prentice-Hall of India — building and reading project networks. https://www.phindia.com/

Further reading

  • B. C. Punmia & K. K. Khandelwal, Project Planning and Control with PERT and CPM.
  • Jerome D. Wiest & Ferdinand K. Levy, A Management Guide to PERT/CPM.

Sources gathered and fact-checked June 2026. Published values vary by source, sample and method — treat as indicative and confirm against the cited standard before structural use.
