Anatomy of a PV System
The panels are only the visible tip - a working solar installation is a whole chain of parts that carries power from the sunlit surface, through conversion and protection, to the socket, the meter and the grid, and a designer who sees only the modules will misjudge cost, space and integration
You can see the panels from the street. You cannot see the inverter humming in the plant room, the DC cables that are live every daylight hour, or the meter quietly deciding what your solar is worth. Yet those invisible parts decide whether the system works at all.
It is tempting to think of a solar installation as 'the panels'. The panels are what you photograph, what the brochure shows, what a client points at. But a photovoltaic system is a chain, and the modules are only the first link. Sunlight lands on the modules and they produce direct current (DC); that DC has to be carried, safely and with minimal loss, along cables and through isolators to an inverter; the inverter converts it to the alternating current (AC) the building and the grid actually use; that AC joins the building at the consumer unit, passes a meter that records what flows each way, powers the loads, and sends any surplus out to the grid. Take any link out and nothing useful happens.
For a designer this matters in three very practical ways. First, space and integration: the inverter, isolators, cable runs and (sometimes) batteries need real, ventilated, accessible room that must be planned early, not discovered on site. Second, cost: the modules are often less than half the installed price - everything else, the balance of system, makes up the rest, and in a BIPV facade it can dominate. Third, honesty: understanding the whole chain is what lets you talk sensibly to the engineer, question a suspiciously cheap quote, and know which decisions are yours (where the array goes, how it reads architecturally, where the plant lives) and which are firmly the engineer's and the utility's (sizing, protection, connection). This lesson gives you that whole-system mental model - sun to socket - so the rest of Module 2 has something to hang on.
Sun -> modules (DC) -> wire + isolator -> inverter -> AC board + meter -> loads -> grid. The panel is one link. Balance of system can cost more than the panels.
The chain, link by link
Follow the power in order and the system stops being a mystery. It begins at the modules - the assembled PV cells on the sunlit surface. Under light they generate direct current (DC): a steady, one-direction flow at a voltage that rises as you wire modules in series into a 'string'. This is the only place generation actually happens; everything downstream is about moving, converting and controlling that power without wasting or endangering it.
From the modules the DC travels through DC cabling - purpose-made, UV-stable, double-insulated cable - to a DC isolator, a switch that lets the DC side be shut off for safety and maintenance. This DC side is important to respect: it is live whenever the sun shines, cannot simply be switched off at the modules, and sits at a voltage that demands proper design. Next comes the inverter, the brain and workhorse of the system, which converts DC into alternating current (AC) - the form the building's wiring and the grid use - and does so while constantly hunting for the point that extracts the most power (more on that in 2.2).
The AC output passes through AC protection (breakers, isolators, earthing) and reaches the building's consumer unit (the distribution board). Here the solar AC mingles with the building's ordinary supply: it first feeds whatever the building is using right now, and only the surplus continues on. A meter records the flows - in a net-metered installation it counts energy going out to the grid as well as energy drawn in. Finally the grid connection links the whole thing to the utility network, which acts as an near-infinite battery: it soaks up surplus and supplies any shortfall.
Running alongside all of this are two quieter systems: the mounting or integration that physically holds the modules (racking on a roof, or the substructure that makes a BIPV element weather-tight), and monitoring that reports how much the system is generating so faults show up. Modules, DC wiring, isolators, inverter, AC protection, consumer unit, meter, grid, mounting, monitoring - that is the anatomy. Learn it as a sequence and you can place, size and cost a system in your head before an engineer ever draws it.
Modules (DC) -> wire + isolator -> inverter (DC to AC) -> AC board + meter -> loads -> grid. The panel is one link in a chain.
DC side and AC side - the great divide
The single most useful way to organise the whole system in your mind is to split it at the inverter into a DC side and an AC side, because they behave differently, carry different risks, and are governed differently.
Upstream of the inverter is the DC side: the modules, the DC cabling, the connectors, the DC isolator. Its defining feature is that it is energised whenever there is light - you cannot 'turn the modules off', only isolate their output - and it runs at a DC voltage that does not have the natural zero-crossings of AC, which makes DC arcs harder to extinguish and DC faults their own discipline. This is why the DC side has strict rules about cable type, routing, connectors, isolation and (increasingly) rapid-shutdown provisions, and why it is squarely engineering territory. For a designer the DC side is mostly about where the modules are and how their cables reach the inverter - runs that should be short, protected, and planned into the fabric, especially in a BIPV facade where cables must be concealed and still serviceable.
Downstream of the inverter is the AC side: AC protection, the consumer unit, the meter, the building's circuits, the grid connection. This is the familiar world of ordinary building electrics - the same alternating current your sockets already use - so it integrates into the building's normal distribution, but with added rules for connecting a generator: anti-islanding (the inverter must disconnect if the grid goes down, so it cannot back-feed a 'dead' line and endanger a lineworker), export limits, and metering.
The practical payoff of this mental split is judgement. When you hear that a system needs a 'string isolator on the roof' or 'rapid shutdown', that is the DC side. When you hear 'net meter', 'export limit' or 'anti-islanding', that is the AC side. The inverter is the border crossing between them. And the honest boundary of your role sits across this whole divide: the architect and interior designer shape *where the array and plant go and how they read*, but the sizing, protection, isolation and connection on both sides are binding engineering that belongs to the electrical engineer, the manufacturer's data and the codes - never to a designer's assumption.
Where the power goes - self-consume, import, export
A system that generates is only half the story; what happens to that power moment by moment shapes its whole value. At any instant the building has a demand (lights, cooling, equipment) and the array has a generation, and the two rarely match. Three things can happen.
When generation exceeds demand, the building uses what it needs and the surplus is exported to the grid. When demand exceeds generation - a cloudy hour, or the evening after sunset - the building uses all the solar it can and imports the shortfall from the grid. And in the sweet middle, all the generation is used on site as it is made: pure self-consumption. This matters commercially because, in most tariff structures, a unit you consume yourself is worth more than a unit you export: self-consumption offsets electricity you would have bought at the retail rate, while export is often credited at a lower rate (the exact rules are the utility's, and vary - Module 8.2). So two systems generating the identical number of units can deliver very different value depending on when they generate relative to when the building uses power.
This single idea explains much of what follows in the course. It is why load-matching matters (a building whose demand peaks at midday, like an office, is a natural fit for solar; a home that peaks in the evening is a poorer instantaneous match). It is why storage exists - a battery lets you park midday surplus and spend it in the evening, converting low-value export into high-value self-consumption (2.3). It is why orientation is not only about total yield: an array angled to catch late-afternoon sun may be worth more to an evening-peaking building than a higher-yielding noon-facing one. And it quietly shapes BIPV, where east and west facades generate at the ends of the day and can broaden the generation curve rather than piling it all at noon.
For the designer, the takeaway is to stop thinking of a solar system as a lump of annual kilowatt-hours and start thinking of it as a shape over the day that meets, or misses, the building's own shape of demand. The closer the two shapes sit, the more the system is worth - a theme we return to in Module 6. As always, the actual tariffs, export rules and net-metering terms are the utility's and the regulator's to set, not the designer's to promise.
Generation vs demand, hour by hour. Surplus -> export (worth less). Shortfall -> import. Match them -> self-consume (worth most).
Why the anatomy matters for a BIPV designer
Everything above is true of any PV system, rooftop BAPV included. But it lands with special force in BIPV, because integration changes where the parts go and what they cost.
First, the balance of system can dominate. On a simple roof, standard racking and short cable runs keep the non-module cost modest. In a BIPV facade, the 'mounting' is a bespoke weather-tight substructure, the cable runs are long and must be concealed yet serviceable, and the modules themselves are custom sizes and shapes. The module may be a smaller fraction of the total than a newcomer expects - which is exactly why BIPV must earn its place (Module 0). Seeing the full anatomy is what stops a designer from quoting 'just the panels' and being shocked by the real number.
Second, the plant needs a home. Inverters (and any batteries) need a ventilated, accessible, often cool space - a real architectural requirement. Put an inverter in a sealed, sun-baked cupboard and it will run hot, derate and fail early. This is a coordination task the designer owns: find the space, plan the cable routes, keep runs short, and give maintenance access, all early enough that it is designed in rather than bodged on.
Third, integration multiplies the DC-side considerations. A facade full of modules means DC cabling threaded through the building envelope, connectors buried behind cladding, isolation and (where required) rapid-shutdown provisions to think about with the engineer from the start. A module that is beautiful but unserviceable, or a cable route that cannot be inspected, is a design failure even if the array generates well on day one.
Fourth, the whole-system view is what makes you a good client of the engineer. You are not going to size the strings or specify the protection - and you should not. But if you understand the chain, you can ask the right questions (Where does the inverter live? How long are the DC runs? What is the balance-of-system cost? How does anti-islanding affect backup?), catch a quote that has hidden the plant space, and integrate the system honestly rather than treating it as a black box bolted to your building. The generation is the modules; the *system* is the anatomy - and design happens across the whole of it.
DC side vs AC side
The system split at the inverter
DC side (modules, DC cabling, isolator) is live in daylight and has its own strict rules; AC side (consumer unit, meter, grid) is the building's normal electrics plus generator rules. The inverter is the border. Lessons 2.1, 2.2, 7.1.
Balance of system (BOS)
Everything that is not the module
Inverter, cabling, protection, mounting/integration, metering, monitoring. Can equal or exceed module cost in BIPV. A real budget line, not 'just wiring'. Lesson 2.2.
Anti-islanding & connection
Safely feeding the building and grid
A grid-tied inverter must disconnect if the grid fails (anti-islanding), so it cannot back-feed a dead line. Connection, metering and export follow the utility/DISCOM and the codes. Modules 7.1, 8.2.
Sizing, protection & isolation
Whether the system is safe and correctly rated
String sizing, cable rating, DC/AC protection, isolation, earthing and any rapid-shutdown belong to the qualified electrical engineer, the manufacturer's data and the governing codes (NBC, IS/IEC, CEA) - never a designer's assumption. Module 7.
Workshop - trace a real system from sun to socket
You understand the anatomy once you can trace it on a real installation. In this workshop you follow the power through a system you can see (or a clear photo/case study) and map every link, then locate the parts a brochure never shows.
A solar installation you can look at (or a good case study/photo set), this lesson's one-line diagram, and a notebook. No calculation - this is about seeing the whole chain; sizing and protection are the engineer's.
Goal: a labelled sun-to-socket trace of one PV system Inputs: a solar installation you can observe, or a detailed case study/photo set + this lesson Time: ~45 minutes
- 1Find the generation: locate the modules and note the surface they sit on - roof, facade, canopy - and roughly their orientation. This is the only place power is made; label it 'DC source'.
- 2Follow the DC side: sketch the likely path from the modules to the inverter - the DC cabling and the DC isolator. Mark this whole run 'live in daylight' and note where the cables would have to go in this building (and, if BIPV, whether they could be concealed and still serviced).
- 3Find the inverter and the border: locate (or reason out) where the inverter lives, and check honestly whether that space is ventilated, accessible and not baking in the sun. Draw the inverter as the DC-to-AC border.
- 4Trace the AC side: from the inverter, follow the AC to the consumer unit, the meter and the grid connection. Label where the building's own loads tap in, and where surplus would export.
- 5Cost and reflect: estimate, qualitatively, how big the 'balance of system' is versus the modules for this installation (small on a plain roof, large on a BIPV facade), and write two sentences on what a designer would need to plan early that a 'just the panels' view would miss - all flagged as a qualitative trace, with sizing and safety left to an engineer.
You’ll walk away with
A one-page annotated sun-to-socket diagram of one real system: modules, DC run + isolator, inverter, AC board, meter, grid, plus where the plant lives - with a note on the balance-of-system share and what a designer must plan early. Reasoning, not a specification.
Three altitudes on the same idea
Read the band that fits you — or all three.
A PV system is a chain, not a set of panels, and you design across the whole of it - so plan the invisible parts as deliberately as the visible array. The modules make DC; wiring and isolators carry it; the inverter makes AC; the consumer unit, meter and grid finish the job; mounting and monitoring run alongside. Your decisions: where the array sits and how it reads, where the inverter and any batteries live (ventilated, accessible, cool), how DC runs are routed and concealed yet serviceable, and how the balance-of-system cost - which can dominate in BIPV - is honestly carried in the budget. Split the system at the inverter into a DC side (live in daylight, strict rules) and an AC side (grid connection, metering, anti-islanding) so you know what you are looking at. Own the integration and the plant-space coordination; defer sizing, protection, isolation and connection to the electrical engineer, the manufacturer and the codes.
The system's shape over the day is what meets - or misses - the interior loads you influence, and its plant needs interior space you must find. Lighting, plug loads and cooling are much of a building's demand, and their timing decides how much of the solar is self-consumed (worth most) versus exported (worth less). Understanding self-consumption, import and export lets you help shape a building whose demand sits under its generation curve. Practically, the inverter and any batteries need a real, ventilated, accessible home - a plant space that is your coordination too, not an afterthought in a sealed cupboard - and solar glazing brings the DC/AC chain into the very surfaces you specify for daylight and view. Coordinate binding electrical and space-planning matters with the engineer; your domain is the humane interior, the loads it drives, and finding proper room for the system that powers it.
Learn the whole chain - modules, DC wiring, isolator, inverter, AC board, meter, grid, plus mounting and monitoring - as an ordered sequence, and the rest of the course clicks into place. Generation happens only at the modules (DC); the inverter converts DC to AC; the grid balances surplus and shortfall. Master two mental tools: the split at the inverter into a DC side (live in daylight, arcs hard to quench, strict rules) and an AC side (metering, anti-islanding, connection); and the moment-by-moment story of self-consumption versus import versus export, which explains why load-matching, orientation timing and storage all matter. You are not expected to size or protect a system - that is the engineer's binding work - but you are expected to picture the anatomy, know the balance of system can cost more than the panels (especially in BIPV), and understand why the plant needs proper space. This whole-system literacy is what separates a designer from a brochure-reader.
“A solar system is basically the panels. Once you have chosen the panels and worked out how many fit, the rest is just wiring - a minor, cheap detail the installer handles, and the panels are where nearly all the cost and all the design decisions live.”
Do it yourself
No tools needed - reason it through.
- 1List the links of a grid-tied PV system in order from the modules to the grid, and say what each one does.
- 2Explain the split into a DC side and an AC side: where is the border, and why does the DC side carry particular risks?
- 3Distinguish self-consumption, import and export, and explain why a self-consumed unit is usually worth more than an exported one.
- 4Why can the balance of system cost as much as or more than the modules in a BIPV facade, and what does that mean for a budget?
- 5What must a designer plan early for the inverter and any batteries, and which parts of the whole system must be deferred to the engineer and the utility?
